DriverChecker - Find Malicious Drivers on a System

I’m proud to introduce DriverChecker, a tool that will scan all loaded drivers on a system for any that may be suspicious/malicious in nature! This blog post will supplement the GitHub repository for the tool, outlining the various modules that the tool uses to try to detect any potentially suspicious drivers. The GitHub repository can be found here.

Detection Techniques

Below is a list of the current modules that DriverChecker uses to try to find maliciously loaded drivers:

Nonexistent Files

This module attempts to locate any loaded kernel drivers that have no associated driver file on the filesystem. The purpose of this module is to find any drivers that may have been loaded directly from memory; some malware samples will embed a driver directly into themselves, then attempt to load it at runtime without dropping the driver file to disk first. This module can contain some false positives, as Windows itself will load some “virtual” drivers on boot, mostly pertaining to creating crash dumps. More information on these virtual drivers can be found here.

File Extension

Normal driver files have a file extension of “.sys”, but malware will sometimes drop drivers to the system using randomized or masqueraded file extensions to try to hide the true purpose of the file. While this may hide that the file is a driver from anyone who looks at it in explorer, it raises a huge red flag for any drivers loaded into the kernel, as any legitimate application will use the standardized extension for drivers that Windows recognizes. Due to this, it is rather unlikely that any driver found under this category will be a false positive, making this a high fidelity detection module.

File Path

Drivers, and especially kernel drivers, should be placed in a directory that is protected with appropriate file permissions, only allowing an administrator or SYSTEM to modify the files. As such, most Windows drivers are placed in the C:\Windows\System32\drivers directory, or sometimes C:\Program Files, to make sure they cannot be tampered with. Malware, on the other hand, generally needs to drop files to the filesystem in places that are world writable, or atleast writable by a standard user. Common locations for this generally include: C:\ProgramData, C:\Users\<user>\AppData, C:\Users\Public, and so on. This module looks for any loaded drivers that were loaded from a non-standard location, potentially indicating a maliciously loaded driver.

Trust Verification Failed

Driver Signature Enforcement (DSE) has been a component since Windows Vista that requires all drivers loaded into the operating system to be digitally signed. Since Windows 10, this driver signing policy has become even more strict, also requiring a digital signature to be present on the driver from Microsoft via the Windows Hardware Developer Center. This module verifies that all loaded drivers have such a digital signature, by using the WinVerifyTrust API to check to see if the driver file has an embedded signature or one from a catalog file. According to Windows policy, any kernel mode boot-start driver (one that loads during the boot process) must have an embedded signature, whereas any kernel mode non-boot-start driver can have either an embedded or catalog-based signature. More information on this differentiation can be found here. This module is unlikely to find any such drivers loaded, as Microsoft has significantly locked down what can load into the kernel in a standard manner. That being said, it is possible to disable DSE on a system, allowing any driver to be loaded into the kernel, so this module can help discover a computer that may be in this state.

LOLDrivers

The website LOLDrivers.io maintains a list of known, legitimately signed drivers that can be used to perform malicious activity on a system. Whether this is killing security services, allowing arbitrary read/write from anywhere in memory, manipulating kernel callbacks, there are many techniques that these types of drivers can allow a threat actor to perform on a system when it is loaded. These are known as Bring Your Own Vulnerable Driver (BYOVD) techniques and have become increasingly popular among threat actors, particularly for killing security products (known as EDR Killers) on an infected system. This module will reach out to LOLDrivers to obtain the most up-to-date list of vulnerable drivers and compare that list against all currently loaded drivers to determine if any many be present on the system. There may be some false positives with this module, as a number of legitimate Windows drivers that are actively used by the operating system or various applications may contain such a vulnerability that would allow a threat actor to compromise the system.

Examples

Below are some examples of this tool in action against legitimate malware samples that involved some sort of malicious driver load as part of their infection process.

EnCase Driver

Below is the output of the tool after executing an EDR killer malware sample that used a vulnerable EnCase driver to terminate processes on the system:

The above malware sample write-up can be found here.

GentleKiller

Below is the output of the tool after executing a sample of GentleKiller, a well-known EDR killer malware strain:

The above malware sample write-up can be found here.

Conclusion

DriverChecker will be continually updated to include new modules to help identify any suspicious or malicious drivers loaded on to a system. If you have any ideas for enhancements, shoot me an email or open up an issue on the GitHub repository.
